Pneumatic Precision Planters
The Foldable Pneumatic Precision Planter Disc Type – AHTAPOT D is designed for high-capacity precision planting with maximum convenience. Thanks to its foldable frame, transportation between fields is quick and easy while meeting road transport requirements. Its pneumatic precision metering system ensures accurate seed placement and uniform spacing, promoting consistent crop emergence and higher yields. The robust construction and hydraulic folding mechanism provide reliable performance, easy operation, and long service life under demanding field conditions.
|
Technical Specificaions* |
Unit |
AHTAPOT D8 |
AHTAPOT D10 |
AHTAPOT D12 |
|
Number of Rows |
pcs |
8 |
10 |
12 |
|
Total Width (W) |
mm |
6000 |
7800 |
9000 |
|
ft.in. |
19'8" |
25'7" |
29'6" |
|
|
Total Length (L) |
mm |
2400 |
2400 |
2400 |
|
ft.in. |
7'10" |
7'10" |
7'10" |
|
|
Total Height (H) |
mm |
3650 |
3650 |
3650 |
|
ft.in. |
11'11" |
11'11" |
11'11" |
|
|
Working Depth |
mm |
0-100 |
||
|
ft.in. |
0"-4" |
|||
|
Seed Hopper Volume |
dm3 |
40X8 |
40X10 |
40X12 |
|
Space Between Rows (B) |
mm |
450x750 |
450x750 |
450x750 |
|
ft.in. |
1'5"x2'5" |
1'5"x2'5" |
1'5"x2'5" |
|
|
Working Speed |
km/h |
4-8 |
||
|
PTO Rotation |
rpm |
540 |
||
|
Tyre Size |
6.5X80-15 |
|||
|
Required Power |
hp |
100-120 |
120-130 |
130-150 |
|
Weight without Fertilizer Hopper |
kg |
1850 |
2000 |
2180 |
|
Ibs |
4078 |
4409 |
4806 |
|
PNEUMATIC PRECISION PLANTER DISC TYPE
_F.jpg)
PNEUMATIC PRECISION PLANTER DISC TYPE, VARY SPACE, HYDRAULIC ROW SPACE CONTROL
_F.jpg)
PNEUMATIC PRECISION PLANTER DISC TYPE, VARY SPACE FOLDABLE, HYDRAULIC ROW SPACE CONTROL
_F.jpg)
TWIN ROW PNEUMATIC PRECISION PLANTER DISC TYPE
TRIPLE ROW PNEUMATIC PRECISION PLANTER DISC TYPE
PNEUMATIC PRECISION PLANTER DISC TYPE, TRAILED, FOR WORKING POSITION
PNEUMATIC PRECISION PLANTER DISC TYPE, TRAILED, FOR TRANSPORT POSITION
NO-TILL PNEUMATIC PRECISION PLANTER DISC TYPE
