The Casting Roller Trailed Foldable Type is designed for efficient soil compaction and high-capacity field performance. Its heavy-duty cast rollers break down large clods, level the soil surface, and improve soil-to-seed contact while helping to retain moisture for better germination. The foldable frame allows easy transport and compact storage, making it ideal for working on large fields while complying with road transport requirements. Its robust construction ensures reliable and long-lasting performance under demanding field conditions.
|
Technical Specifications* |
Unit |
BIZON F 630 |
BIZON F 830 |
BIZON F 950 |
|
Total Width (W) |
mm |
2300 |
2300 |
2300 |
|
ft.in. |
7'7" |
7'7" |
7'7" |
|
|
Total Length (L) |
mm |
3500 |
3500 |
3500 |
|
ft.in |
11'6" |
11'6" |
11'6" |
|
|
Total Height (H) |
mm |
1500 |
1500 |
1500 |
|
ft.in. |
4'11" |
4'11" |
4'11" |
|
|
Working Width |
mm |
6300 |
8300 |
9500 |
|
ft.in |
20'8" |
27'3" |
31'2" |
|
|
Roller Diameter (D) |
mm |
500 |
500 |
500 |
|
ft.in |
20" |
20" |
20" |
|
|
Required Power |
hp |
90-100 |
110-120 |
130-150 |
|
Weight |
kg |
3200 |
4100 |
4840 |
|
Ibs |
7054 |
9038 |
10670 |
Casting Roller, Foldable and Trailed Type / BIZON F
